- Super Compact & Lightweight
- ･ 500W x 1ch in 2U chassis height
･ 3.9Kg in weight, one third of conventional models
- Energy Saving Technology for Longer Life of Battery
- ･ Up to three times compared to analog amps.
･ Low Power Consumption Half compared with the conventional at 1/8 rated power
- High Output Power:500W/8Ω
- ･ Rich bass sound reproduction (Original Bi-Phase PWM is advanced)
･ Suitable for sound reinforcement with fast and lively sound
- Easy mounting & Operation
- ･ Mounting Kit MK-M524(for EIA 19" inch Rack; option)
･ Front Panel I/O Connectors
- Superb Driving Capability
- The Floating Full-Resonance Switcing Power Supply delivers a high speed resonanse.
- Dual(Analog & Digital)NFB ensures stable amplification
- and isolation from voltage fluctuation. Also achieved is superb resolution and linearity from minimum to maximum output.
- Built-in Real Time Current Limitter
- Keeping amplifier in safety operation area for high level input to achieve higher reliability and continuous operation.
- Green Technology: Low Power Consumption thanks to very high conversion efficiency
- At Rated Output of 500W/8Ω: 80% (Conventional Analog Amplifier:30-40%)
| Rated Output Power | 500W x 1ch/8Ω&4Ω |
|---|---|
| Frequency response | 20-20kHz (1W/8Ω, 0±0.5dB) |
| Total Harmonic Distortion | 0.5% (250W/8Ω&4Ω/1kHz) |
| S/N ratio | 114dB (400Hz-30kHz BPF) |
| Input Sensitivity | +6dBV±1dB/1kHz |
| Input Impedance | 25kΩ±5% |
| Power Consumption | 95W / 8Ω |
| Overall Dimensions | 213.5(W) x 88(H) x 385.8(D) ㎜ 8-1/4"(W) x 3-7/16"(H) x 15-1/8"(D) |
| Weight | 3.9kg(8.6lb) |
Feature
