- Super Compact& Super Light-weight
- 300W/4ohm Output Power with the nearly same size as DAD-M100proII.
- Flying Mole Original Bi-Phase PWM Amplification
- ensures Tube-like HiFi sound with Speed and Dynamic s of Solid State Amp. Latest Bi-Phase PWM(3-Level PWM) Amplification ensures superb sound quality in moderate power range.
- Dual (Analog & Digital) NFB ensures stable amplification
- and isolation from voltage fluctuation.It achieves superb resolution and linearity from minimum to maximum output.
- DC Amplifier Configuration
- The DC amplifier configuration ensures rich bass, clear musical scale bass with strong powerful presence.
- Built-in Real Time Current Limiter
- Keeping amplifier operation in Safety Operation Area for high level input to achieve higher durability and continuous operation.
- Green Technlogy: Low Power Consumption thanks to very high conversion efficiency
- At Rated Output 100W/8Ω: 85% (Conventional Amplifiers: 30-40%)
At normal music listening level 60% (Conventional Amplifiers: 5-8%)
| Rated Power Output | 180W ｘ1ch/8Ω 300W x1ch/4Ω |
|---|---|
| THD | 0.05% (90W/8Ω/1kHz) |
| Frequency Response | DC - 20kHz (+0dB/-0.5dB)/ 8Ω DC - 50kHz (+0dB/-3.0dB)/ 8Ω |
| S/N Ratio | 120dB(Input shorted,400Hz-30kHz BPF) |
| Input Sensitivity | 1V |
| Input Impedance | 10kΩ (Vol. MAX) |
| Power Consumption | 55W |
| Overall Dimensions | HT-&BB-type: 134.5(W) x 45(H) x 305(D)mm 5-3/16"(W) x 1-1/2"(H) x 12""(D) BI-type: 134.5(W) x 45(H) x 289(D)mm 5-3/16"(W) x 1-1/2"(H) x 11-1/4""(D) |
| Weight | 1.0Kg(2.2lb) |
