The drive to create a pre-amp that delivers the highest audio quality, paying attention to even the smallest sound, was achieved with many original technologies and ideas.
- Dual Monaural Construction
- Independent power supply for each channel allows high speed signal transfer with minimal mutual interference and enables an exceptional sound quality that is fast and crystal clear.
- Introducing the New One Pole Pre-Amplifier
- Active Control circuitry enables accurate volume control by eliminating contact electrical losses. It also protects against sound quality deterioration by removing influences of characteristic changes, enabling high quality sound enjoyment at any output level.
- Non-contact circuitry construction
- Newly developed logic circuitry for the signal input selector completely eliminates enroute signal contact.
- DC Amp Circuit Construction
- Employing the DC Amp construction, the DC-50kHz frequency characteristics provide a sonorous bass, clear musical scales and an encompassing musical presence.
- Flying Mole’s proprietary Bi-Phase PWM technology
- In order to eliminate wave fluctuations that cause sound distortion, Flying Mole split the PWM signal into two broader Bi-Phase signals. The digital amp then converts these into high quality HiFi signals, while the new Pre-Amp circuitry further improves total sound quality, especially the resolution and linear reproduction of subtle signal levels. In addition, dual (analog & digital) NFB eliminate sound corruption caused by AC power voltage fluctuation, to produce audio of the highest quality, reliability and stability.
- High power - full resonance switching power supply
- Independent floating power circuitry for both the right and left channels enhances and ensures stability for the power amp as well as powerful support for high audio quality.
- Settling for nothing but the best in both parts and design
-
- At its thickest, the front panel is 10mm of non-magnetic pure aluminum.
- The pure aluminum casing provides both extreme rigidity and damping
- Pure aluminum dials (volume control & input selector)
- Gold plated brass speaker terminals
- Gold plated brass pin jacks (3 input, 1 pre-out)
- Designed by the world renowned GK Industrial Design Company
- Mechanical volume control created by human engineering
- Fine tuning taken to the extreme and introduced to an amp already known for its high quality and 27 level volume control. The aluminum dial offers a sensitive touch that can not be imitated.
- Designed with environmental protection in mind
- Low power consumption and compact size lead to 85% power efficiency. This in turn contributes to energy conservation while reducing necessary resources.
| Rated Output | 100W ×2 / 8Ohms 160W ×2 / 4Ohms |
|---|---|
| T.H.D. | 0.05% （@50W/8Ohms/1kHz） |
| Frequency Characteristics | DC -20kHz（ +0dB/-0.5dB）（/ 8Ohms） DC -50kHz（ +0dB/-3dB）（/ 8Ohms） |
| Channel Separation | >70dB （20kHz） |
| S/N Ratio | 120 dB (Revised Input Short) |
| Residual Noise | 25 μV |
| Input Sensitivity | 150mV （Line in） |
| Input Impedance | 10kOhms |
| Power Consumption | 62W |
| Outer Dimensions | 281（W）×54（H）×253（D）mm (11-1/16"x2-1/8"x9-15/16") |
| Max. Outer Dimensions | 281（W）×60（H）×292（D）mm (11-1/16"x2-3/8"x11-1/2") |
| Weight | 8 lbs 12oz (4kg) |
